Example Brand Reference · Meridian GMT
Two time zones.
One honest record.
This is an example. The Meridian GMT is a fictional watch from the Watch Vault Archive sample collection, used to show what a Brand Reference page looks like. Its specifications and timing record are invented.
The case
Titanium, worn the way steel never is.
Thirty-nine and a half millimetres of grade 5 titanium, brushed, with polished chamfers catching the light at every edge. The head weighs 78 grams. On the wrist it disappears; under a loupe it does not.
Hardened to 340 Vickers, so the brushing keeps its line. A fixed titanium bezel with a coin edge and a sixty-minute scale, flat sapphire coated on both sides, a screw-down crown, and 150 metres of water resistance.
The movement
Built for the long way round.
Calibre AV-330, automatic and made in-house: a second time zone, the day and the date, and 56 hours of power reserve beating at 4 Hz. Certified as a chronometer by the COSC.
Through the sapphire case back you can watch twenty-five jewels at work. Rated to resist magnetism to 4,800 A/m, because the modern world is full of it.
The record
What two years on the wrist showed.
A specification says what a watch should do. A record says what one did. This example was put on a timegrapher six times in two years, at the same independent watchmaker, on the same machine.
It ran fourteen seconds a day fast from new. Regulated five weeks later, it read two. For a year and a half it held within a few seconds either way. Amplitude came down about ten degrees a year, nothing sudden, until the latest reading of 235° showed the trend its service interval exists for. It passed a dry pressure test to 150 metres along the way.
| Date | Rate | Amplitude | Beat error |
|---|---|---|---|
| Sep 2024 | +14 s/d | 288° | 0.2 ms |
| Nov 2024 | +2 s/d | 291° | 0.1 ms |
| Apr 2025 | +5 s/d | 278° | 0.3 ms |
| Oct 2025 | −3 s/d | 265° | 0.4 ms |
| Mar 2026 | +7 s/d | 252° | 0.6 ms |
| Jul 2026 | −12 s/d | 235° | 0.9 ms |
One example, lift angle 50°, measured by an independent watchmaker and kept in Watch Vault Archive. A record of one watch, not a rating of the model.
Specifications
The detail.
- Diameter
- 39.5 mm
- Thickness
- 11.8 mm
- Lug to lug
- 46 mm
- Lug width
- 20 mm
- Material
- Grade 5 titanium, brushed, polished chamfers · 340 Vickers
- Weight
- 78 g, head only
- Bezel
- Fixed titanium, coin edge, 60-minute scale
- Crystal
- Flat sapphire, anti-reflective both sides
- Crown
- Screw-down
- Case back
- Sapphire display
- Water resistance
- 150 m
- Anti-magnetic
- 4,800 A/m
- Calibre
- AV-330, automatic, in-house
- Certification
- COSC chronometer
- Functions
- Hours, minutes, seconds · GMT · day-date
- Beat rate
- 28,800 vph (4 Hz)
- Power reserve
- 56 hours
- Jewels
- 25
- Lift angle
- 50°
- Dial
- Gloss black, rhodium-plated applied indices
- Lume
- Super-LumiNova BGW9, blue-green
- Strap
- Black canvas, 20 mm, titanium pin buckle
- Made in
- Switzerland · limited edition of 500
Keep its record from the first day.
On a real Brand Reference page, a link to the maker's own shop appears here.
